QuickPHOTO MICRO - Microscope Software

QuickPHOTO MICRO Microscope Software Screenshot

QuickPHOTO MICRO is an advanced version of QuickPHOTO microscope software intended mainly for life science and earth science applications. It is developed by PROMICRA since 2004. The program features all the functions of QuickPHOTO CAMERA and additionally provides advanced measuring and reporting functions. It can be used with any brand and type of optical microscope equipped with a photo port.

Features

QuickPHOTO MICRO live view and image acquisition
Image Acquisition and Live View

Image acquisition and live view from a wide range of imaging devices (microscope digital cameras, DSLR cameras, analog cameras, scanners)

Annotations made in QuickPHOTO MICRO microscope imaging software
Annotations and Editing

Text annotations, indication of interesting areas, crop, rotation, flip, mirror, resize, brightness, contrast, color balance, histogram adjustment, filters, white balance, black balance

QuickPHOTO MICRO measurements
Measurements

Measurements in acquired images and in live view*. Measured values are displayed in a well-arranged table with basic statistics. The values can be exported to a Microsoft® Excel® file or a text file.
*measurements in live view is available for Lumenera INFINITY and PROMICAM cameras only

QuickPHOTO calibration
Calibration

Simple way to calibrate different objectives and zoom positions. The calibrations are protected by a digital signature and can be locked with a password protection.

QuickPHOTO reports - biology
Reports

Images with tables of measured values can be very easily exported into reports in Microsoft® Word format. Users can create custom report templates with various layouts and number of images.

QuickPHOTO time-lapse module
Time-Lapse Capturing

Automatic time-lapse image capturing with the option to control computer controlled illuminators.

QuickPHOTO time-lapse video module

Time-Lapse Video

The built-in Time-Lapse Video module can be used to create HD video clips (with resolution up to 1920 x 1080 pixels) from time-lapse captured images.

QuickPHOTO localization
Localization

Multilingual user interface: English, German, Czech, Slovak, Polish, Spanish, Hungarian, Russian, Ukrainian, Traditional Chinese

QuickPHOTO MICRO advanced saving
Advanced Saving

Advanced functions for saving of multiple images at once. Option to automatically save acquired images to a predefined folder.

QuickPHOTO MICRO two-monitor workstation
Two-Monitor Workstation

The main program window can be displayed on primary display, while the camera control panel with a live view from a microscope can be displayed on secondary display.

Measurement Features

QuickPHOTO INSUSTRIAL - imperial and metric units
Metric and Imperial Units

Measuring in metric as well as imperial units: µm, mm, in, mils, thou.

QuickPHOTO MICRO scale bar
Scale Bar

Insertion of a calibrated scale bar (options to define type, size and colors; vertical or horizontal position)

QuickPHOTO MICRO dimensions
Dimensions

Measuring of dimensions (line segment and polyline)

QuickPHOTO MICRO areas and perimeters
Areas and Perimeters

Measuring of areas and perimeters (ellipse, rectangle, polygon)

QuickPHOTO MICRO angles
Angles

Measuring of angles (arbitrary angle, angle from the X axis, angle from the Y axis)

QuickPHOTO MICRO objects counting
Object Counting

Manual counting of objects. Options for counting of different groups of objects.

QuickPHOTO MICRO phases analysis
Phase Analysis

Measuring of percentage amounts of particular phases in the image

Overlay Grid

Display of a calibrated overlay orthogonal grid

Optional Features

System Requirements

 Minimum RequirementsRecommended Specifications
ProcessorSingle-core 2.4 GHzMulti-core processor
Operating Memory1 GB2-4 GB
USB Ports2x USB 2.0/3.02x USB 2.0/3.0
Operating SystemMicrosoft® Windows®
XP(SP3)/Vista®/7/8/8.1/10
Microsoft® Windows®
7/8.1/10
Display Resolution1024 x 7681920 x 1080
Minimum Requirements
ProcessorSingle-core 2.4 GHz
Operating Memory1 GB
USB Ports2x USB 2.0/3.0
Operating SystemMicrosoft® Windows®
XP(SP3)/Vista®/7/8/8.1/10
Display Resolution1024 x 768
Recommended Specifications
ProcessorMulti-core processor
Operating Memory2-4 GB
USB Ports2x USB 2.0/3.0
Operating SystemMicrosoft® Windows®
7/8.1/10
Display Resolution1920 x 1080
